This repository contains some code that was supposed to help me fix my avatar in Resonite, which turned out to not be appropriate for public instances.
Unfortunately I have yet to actually make the round-trip back into Resonite work properly. Unsure if I'm mapping the bones correctly.
How it works
Because Resonite does not (yet) allow "skinned" meshes (with bones and weights and all that stuff) to be exported in a way that keeps the skinning information, we have to go about it in a more roundabout way:
- Export the model as a Resonite Package, place in
test/Test.resonitepackage - Open the package, which is actually just disguised
.ziparchive - Parse the
R-Main.recordentry, a JSON file - The
assetUrifield points to the main asset file in the archive - Parse this file using BSON, a horrible "Binary JSON" format
- The resulting
DataTreecontains the hierarchical node and component info - Types are encoded as IDs, which we can decode using a lookup array
- Process supported asset types: Meshes, textures, and materials
- These assets can then be referenced by their ID by other nodes
- Go through all node and attach meshes to them if they have some
- Export the whole thing as a
.glbwith SharpGLTF
NOTE: It might be possible to parse a good chunk of this with Resonite's
own library, but it probably requires setting up an Engine or so for it to
parse all the related files, I don't have the know-how to do that.
